DripDoser
The Water Well Oiler that Saves Money!
Provides you with a return on investment in less than one year.
The DripDoser is a gravity-based oiler for Vertical Turbine Pumps that saves thousands of dollars and costly down time.
- Reduces pump maintenance costs.
- Reduces labor cost – checking oil levels and adjusting drip rate.
- Reduces oil consumption and prevents well contamination.
- Maintains constant oil drip rate.
- Protects your irrigation turbine pump from running dry:
- Detects oil loss
- Detects clogged or pinched delivery line.
- Automatic pump shutdown.
- Telemetry compatible remote control and monitoring.
- Maintenance free and easy to install.
- Operates under extreme weather conditions.
- Low price – Fast ROI.
Save Money
- Saves time – reducing the number of well visits.
- Economical – Fuel and vehicle maintenance.
- Oil – drip oil only when required.
- Downtime – Line shaft repairs.
For pre-lube, the pump operator can start the DripDoser prior to starting the pump. For pre-season lubrication, the pump operator can adjust the unit manually without energizing the DripDoser.
DripDoser Specification
| Supply voltage | 100 VAC to 240 VAC, 50/60 Hz |
| Power consumption (max.) | 10 W |
| Drip rate alarm settings | 10, 20, 30, 40, 50 dpm |
| Pump OK relay contact | 110 VAC – 5 A ; 250 VAC – 5A |
| Alarm relay contact | 110 VAC – 5 A ; 250 VAC – 5A |
| Oil on/off solenoid | 12 VDC (internal voltage) |
| Drip volume | 32 drops per 1 cc |
| Oil inlet/outlet | Male thread ¼” BSP |
| Dimensions (W x H x D) | 8.58 x 8.00 x 3.54 inches (218 x 203 x 90 mm) |
| Weight | 3.7 lbs. (1.7 kg) |
All specifications shown are subject to change.
